PVC Coated Galvanized Steel Wire
Available Color: Green / Black / Beige / Blue / Red / Yellow / Voilet/ Gery & Etc. Also, we provide Custom RAL Colors as per customer and project requirements
Standards: ASTM / BS EN / DN / JIS / Customers Specifications
| Technical Properties | Specification Range (SI Units) | Specification Range (Imperial Units) |
|---|---|---|
| PVC Coated Wire Diameter | Ø 2.80mm to 4.88mm | Ø 0.11” to 0.192” |
| Core Steel Wire Diameter | Ø 1.80mm to 3.76mm | Ø 0.071” to 0.148” |
| Tensile strength | 340 to 540 N/mm2 | 49.3 to 78.3 Ksi |
| Zinc Coating | 40 – 366 gms/m2 | 0.15 – 1.20 oz/ft2 |
| Coil Weight | 250 to 750 kgs / Rolls | 551.2 to 1653.5 lbs/Rolls |
Product & Manufacturing Excellence
Our PVC Coated Galvanized Steel Wire is produced on a state-of-the-art, sophisticated computerized advanced production line equipped with cutting-edge technologies, our PVC Coated Galvanized Steel Wire ensures the product uniform quality consistent and top-tier quality performance.
The product features a high-strength good malleability, ductility galvanized steel core coated with PVC Coating UV-resistance, providing superior corrosion resistance, reliability, flexibility and long service life durability, suitable for End application i.e. industrial, agricultural, high-security applications,
Product & Quality Assurance
Our in-house Quality Control Department is fully equipped with modern computerizes testing equipment and operates in full compliance with both national and international standards, each product batch undergoes thorough quality checks to ensure it meets both technical specifications and client requirements.
End Applications of PVC Coated Galvanized Steel Wire
- Security & Boundary Fencing: Chain link Fence, High Security Fences, Barbed Wire, and Gabion Box & Fence Etc.
- Agricultural Use: Vineyard wires, Greenhouse frame wires, and Poultry fencing
- Packaging & Construction: Bale wires, Wire ties, Packaging wire, Binding wire, Construction ties Etc.
- General Purpose: Custom applications based on project requirements
