Hot Dip Galvanized Steel Wire Heavy Coated
Standards: ASTM / BS EN / DN / JIS / Customers Specifications
| Technical Properties | Specification Range (SI Units) | Specification Range (Imperial Units) |
|---|---|---|
| Diameter | Ø 2.00mm to 5.00mm | Ø 0.079” to 0.197” |
| Tensile Strength – Soft | 340 to 500 N/mm2 | 49.31 to 72.51 Ksi |
| Tensile Strength – Medium | 500 to 650 N/mm2 | 72.50 to 94.27 Ksi |
| Tensile Strength – Hard | 650 to 1500 N/mm2 | 94.30 to 217.55 Ksi |
| Zinc Coating | 150 – 610 gms/m2 | 0.49 – 2.0 oz/ft2 |
| Coil Weight | 250 to 1000 kgs / Rolls | 551.2 to 2204.6 lbs/Rolls |
Product & Manufacturing Excellence
Our Hot Dip Galvanized Steel Wire Heavy Coated, is produced on a state-of-the-art, sophisticated computerized advanced production line equipped with cutting-edge technologies, our Hot Dip Galvanized Steel Wire with Heavy Coating is ensures the product uniform quality consistent and top-tier quality performance.
The product features are made from high-strength steel wire, good malleability, ductility and coated with Special High-Grade Zinc, our Hot Dip Galvanized Steel Wire Heavy Coated is features an excellent smooth, durable coating that provides essential corrosion resistance ensures long-lasting protection, and suitable for all applications i.e Fence, Gabion, Welded Mesh, Steel Nail, Screws & Fasteners, Core wire for ACSR, vineyard wires, bale wires, and Wire ties Etc
Products & Quality Assurance
Our in-house Quality Control Department is fully equipped with modern computerizes testing equipment and operates in full compliance with both national and international standards, each product batch undergoes thorough quality checks to ensure it meets both technical specifications and client requirements.
End Applications and Uses
- Fencing Solutions: Chain link Fence, Welded Mesh Fence, High Security Fences, Animal Fence, Barbed Wire, Block mesh and Gabion Fence Etc.
- Fasteners and Hardware: Steel Wire Nail, Steel Nail and Screws and Fasteners Etc
- Agricultural and Horticultural Uses :Trellis wires, vineyard wires, bale wires, Wire ties, Packaging wire, Construction ties Etc.
- Electrical and Transmission Lines: Single Steel Core wire for ACSR
- Industrial & General Applications : Used for All industrial & General application
