Hot Dip Galvanized Steel Wire Commercial Coated
Standards: ASTM / BS EN / DN / JIS / Customers Specifications
| Technical Properties | Specification Range (SI Units) | Specification Range (Imperial Units) |
|---|---|---|
| Diameter | Ø 2.00mm to 5.00mm | Ø 0.079” to 0.197” |
| Tensile Strength – Soft | 340 to 500 N/mm2 | 49.32 to 72.51 Ksi |
| Tensile Strength – Medium | 500 to 650 N/mm2 | 72.51 to 94.27 Ksi |
| Tensile Strength – Hard | 650 to 1200 N/mm2 | 94.27 to 174.05 Ksi |
| Zinc Coating | 50 – 150 gms/m2 | 0.16 – 0.49 oz/ft2 |
| Coil Weight | 250 to 1000 kgs / Rolls | 551.2 to 2204.6 lbs/Rolls |
Product & Manufacturing Excellence
Our Hot Dip Galvanized Steel Wire Commercial-Low Coating, is produced on a state-of-the-art, sophisticated computerized advanced production line equipped with cutting-edge technologies, our Hot Dip Galvanized Steel Wire with Commercial-Low Coating ensures the product uniform quality consistent and top-tier quality performance.
The product features are made from high-strength steel wire, good malleability, ductility and coated with Special High-Grade Zinc, our Hot Dip Galvanized Steel Wire Commercial-Low Coating features an excellent smooth, durable coating that provides essential corrosion resistance, and suitable for all applications i.e Fence, Gabion, Welded Mesh, Steel Nail, Screws & Fasteners, vineyard wires, bale wires, Wire ties, Wire Hangers, and Bucket Handle Etc.
Products & Quality Assurance
Our in-house Quality Control Department is fully equipped with modern computerizes testing equipment and operates in full compliance with both national and international standards, each product batch undergoes thorough quality checks to ensure it meets both technical specifications and client requirements.
End Applications
- Fencing Solutions: Chain link Fence, Welded Mesh Fence, High Security Fences, Animal Fence, Barbed Wire, Block mesh and Gabion Fence Etc.
- Fasteners and Hardware: Steel Wire Nail, Steel Nail and Screws and Fasteners Etc
- Agricultural and Horticultural Uses: Trellis wires, Vineyard wires, Greenhouse frame wires, and Poultry fencing
- Industrial Applications: Bale wires, Wire ties, Packaging wire, Strapping wire, Binding wire, Bucket Handle Etc.
- General Application: Wire Hangers, and Construction ties etc.
